shenzhen jing bang technology co.,ltd

ShenZhen JingBang Technology Co.,Ltd is an expert PCB manufacturing company based in China mainland ShenZhen. Its parent company is HK IBE Group. .With ten years of development, from a small scale printed circuit board company, JB turns into a first class manufacturer that could provide HDI, SMT (Surface mounting technology) service as one unit.JB exclusively offer OEM service to those domestic and overseas high technology enterprise and company. JB was honored as an excellent supplier annually by many well-known companies both at home and abroad, and was defined as the outstanding private individual high technology enterprise by ShenZhen Scientific Technology Bureau. Simultaneously, the HDI, prototype,, medium and batch quantity of PCB and SMT( PCBA) we produced were highly appreciated by ShenZhen High Tech Item Program and we were approved to locate in the New High Tech Park in NanShan District, ShenZhen. JB became ISO9001 certified in Dec, 2001, ISO14000 certified in May 2003 and UL approved in June, 2004, we are planning to apply for the GJB/Z9001A-2001 approval ahead of 2008. We had our own separate offices in Peking, Shang Hai and other small domestic cities. Our businesses extend far into Asia, Europe, America and Australia etc. Through the cooperation with the Japanese, Germany and other developed countries¡¯ customers, we have had adopted international advanced technology and management system, and we have improved our technology level from their high standard and strict quality requirements. The market system of JB is increasingly extending and scale of JB is expanding. We have profuse experience in manufacturing PCB. Our PCB daily capacity is 1200 square meters, we can deliver the SS, DS PCB sample within 24 hours, 4-8 layer PCB in 3-5 working days, for the batch quantity for double side PCB, the lead time is 3-5 working days, 4-8 layer is 5-8 days. The quick and fast lead time stably ensures our customer of quick research speed to occupying the market. For the convenience of better cooperating with our customers, we purchased and reestablished a SMT factory in 2005. By readjusting, rectifying and introducing into advanced management system, adding advanced high speed SMT machine, multifunctional SMT machine, 12 wet HAL lead free hot air reflow machine, ICT testing machine etc facilities, we ensure our customers high quality, speedy SMT sample, prototype and medium batch quantity services. And we set special service such as high difficulty, high density IC Rework and IC soldering (such as BGA chip Rework and soldering, BGA reballing ). We have imported the advanced machinery from US, Japan, German and Israel to improve our production and technical ability. We have set a great example in the PCB field of flying probe testing, buried and blind via and special controlled impedance¡£We have a highly developed R&D division which has helped our factory successfully produce mechanical micro via, high density impedance and HDI.. ¡°Always to think a little bit more for the customer, to do a little bit more for the customer., to set the quality as the route and the service as the basis¡± is the principle of JB. We let our customer feel our real fast, high quality and considerate service by source readjusting and department combination. While in the flow of developing, the workers of the company are united and dedicated to fighting for a first class enterprise with first class culture. Our motto is quality, efficiency and competitive price.¡¡We strictly adhere to the ISO9000 standard, and continuously apply advanced international technology to improve the quality of the product to meet the needs of all our customers.
